Lenovo ThinkPad Universal USB-C Dock Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
Product colour | Black |
---|---|
SKU | 40AY0090EU |
EAN | 0195348192095 |
Manufacturer | Lenovo |
Availability | In Stock |
PDF URLs |
View PDF |

One Dock. No Limits.
Engineered for performance and productivity, the ThinkPad Universal USB-C Dock is compatible with most Windows 10 and above USB-C notebooks2. Ideal for both office-based and remote working, it’s an IT manager’s dream—critical firmware updates are installed automatically and traditional IT tools, such as PXE boot, WOL, and MAC Address Pass Through, are also supported.

One Cable. No Hassle.
With the convenience of 11+ ports, including DisplayPort™ and HDMI™, the ThinkPad Universal USB-C Dock gives you exceptional versatility. It lets you savour blazing-fast data transfers, rapidly charge USB-C notebooks, and plug and play displays and other PC accessories. What’s more, this advanced onecable docking solution gives you more desk-space to work and play with.

One Remote Workforce. No Problem.
Remote dock management just got a whole lot smarter. Thanks to Dock Manager and our latest hardware, firmware updates can be done without any end-user interruption, which means productivity is never compromised
Ports & interfaces | |
---|---|
Combo headphone/mic port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
DisplayPorts quantity | 2 |
Microphone in | No |
Headphone outputs | 0 |
Connectivity technology | Wired |
Network | |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
Performance | |
Maximum digital resolution | 3840 x 2160 pixels |
Number of displays supported | 3 |
On/off switch | Yes |
Product colour | Black |
Card reader integrated | No |
Cable lock slot | Yes |
Certification | FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM |
Cable lock slot type | Kensington |
HD type | 4K Ultra HD |
Technical details | |
Product colour | Black |
Cable lock slot | Yes |
Harmonized System (HS) code | 84733020 |
Compliance certificates | CE |
Storage | |
Card reader integrated | No |
Power | |
Power source type | USB |
Power connector | USB Type-C |
Power supply | 90 W |
Software | |
Windows operating systems supported | Windows 10, Windows 7 |
Operational conditions | |
---|---|
Operating temperature (T-T) | 0 - 35 °C |
Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions | |
Weight | 340 g |
Width | 171 mm |
Depth | 80 mm |
Height | 30.8 mm |
Package weight | 955 g |
Package width | 210 mm |
Package depth | 158 mm |
Package height | 75 mm |
Design | |
Windows operating systems supported | Windows 10, Windows 7 |
Product colour | Black |
Cable lock slot | Yes |
Certification | FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM |
Cable lock slot type | Kensington |
Packaging data | |
Quantity per pack | 1 pc(s) |
Package weight | 955 g |
Package width | 210 mm |
Package depth | 158 mm |
Package height | 75 mm |
Packaging content | |
Cables included | USB Type-C |
Quantity per pack | 1 pc(s) |
Certificates | |
Certification | FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM |
Logistics data | |
Harmonized System (HS) code | 84733020 |
